| General parameters： |
|
|
Typical applications: |
1. ASL：≤2500m
2. Humidity：≤85%
3. Fluid viscosity：0～8000CPS
4. Ambient Temp：0℃～50℃
5. Liquid temperature:－10℃≤T≤100℃
6. Operating mode：uninterrupted duty
7. Medium：acid, alkali, salt, oil, organic solvents
|
|
1. High viscosity filling equipment |
| |
|
| |
|
| |
|
|
|
| |
|
| |
|
|
|
| |
|
|
|
|
|
|
|
| Performance summary: |
|
|
|
|
|
| Date |
Rated Pressure |
Flow rate |
Inlet pressure |
In-Out size |
|
|
|
| Model No |
bar |
ml/rpm |
bar |
mm |
|
|
| LCBS1-06 |
5 |
0.5 |
-1~0.5 |
1/2"EPT |
|
|
|
| LCBS1-12 |
3 |
1 |
|
|
|
| LCBS1-17 |
3 |
1.5 |
|
|
|
| |
|
|
|
|
|
|
|
| Pump construction |
|
Wetted Materials |
|
|
|
| 1. Gear pump |
1. Base material: SS304 |
|
|
| 2. Suction shoe style |
|
2. Gears: PPS, Bronze |
|
|
|
| 3. Spur gears |
|
3. Static Seal: PTFE |
|
|
|
| 4. stationary shafts |
|
|
|
|
|
|
| 5. PTFE bevel or O-ring seal |
|
|
|
|
|
 |
|
|
